Violin head plug BPE 147

2D Plan

Description

This yellow PE threaded plug has a removable side tab to make it easy to remove the plug in hard-to-reach places. It provides a quick and easy solution to remove the part.

Advantages

The base provides good protection for the thread. Thanks to its violin head, the grip is simple therefore the assembly and removal of the conical plug is simple.

Qualities

Tap caps provide optimum protection during manufacture, storage and transport. Illustrations are not contractual.

usage

Can have a number of uses within all industrial sectors. Various thread pitches available

Filter

Material

Color

M

d

L

Pitch

Dimensions
- Material : 106
- Color : 105
- d : M10
- L : 10,0
- Pitch : 1,0
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 10
- d : M10
- L : 10,0
- Pitch : 1,5
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 12
- d : M12
- L : 10,0
- Pitch : 1,0
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 12
- d : M12
- L : 10,0
- Pitch : 1,5
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 12
- d : M12
- L : 10,0
- Pitch : 1,8
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 4
- d : M4
- L : 8,0
- Pitch : 0,7
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 5
- d : M5
- L : 8,0
- Pitch : 0,8
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 6
- d : M6
- L : 8,0
- Pitch : 0,8
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 6
- d : M6
- L : 8,0
- Pitch : 1,0
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 8
- d : M8
- L : 8,0
- Pitch : 1,0
Material : PE-HD
Color : yellow
Minimum sales quantity :
Dimensions
- Material : 106
- Color : 105
- M : 8
- d : M8
- L : 8,0
- Pitch : 1,3
Material : PE-HD
Color : yellow
Minimum sales quantity :
